D16 Heavy Duty 3D Welding Fixture Table for Large Scale Metal Fabrication
Our D16 Heavy Duty 3D Welding Fixture Table is the all-in-one modular work solution for large scale metal fabrication. Featuring 5-sided full D16 hole layout, heavy load reinforced support and anti-deformation nitrided surface, this welding table delivers precise 3D positioning for all oversized heavy metal workpieces.
Ditch costly custom welding jigs — universal D16 accessories enable fast reconfiguration for different products within minutes. High flatness, strong load capacity and long service life make it a staple fixture for steel fabrication factories, robot welding workshops and heavy machinery manufacturers. Multiple dimensions, material choices and auxiliary attachments can be tailored to fit your production demands.
Product Specifications
| Table Dimension (mm) | Table Thickness | Standard Working Height |
|---|---|---|
| 1000 × 1000 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
| 1000 × 1200 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
| 1000 × 2000 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
| 1200 × 2400 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
| 1500 × 2500 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
| 2000 × 3000 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
| 2400 × 4000 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
| 2400 × 4800 | 12mm Q355 / 12mm HT300 | 620mm (Customization supported) |
Key Advantages
While the D28 welding table is often the preferred choice for many heavy-duty applications, the D16 heavy-duty welding table—designed specifically for high-precision, large-scale metal fabrication—offers irreplaceable advantages:
- Superior positioning accuracy: Features a fine 50mm grid and tight dimensional tolerances, ensuring consistent dimensions for large, long components and reducing the need for post-weld correction or rework
- Lightweight tooling accessories: Clamps weigh 50% less than D28 counterparts, allowing for rapid, one-person assembly and disassembly, thereby increasing efficiency when setting up tooling for large workpieces
- Higher hole density: Doubles the density of clamping points, enabling multi-point fixation for extra-long, thin-walled, or irregularly shaped large workpieces to minimize thermal deformation during welding
- Cost advantages: Procurement costs for the table surface and full tooling sets are lower than those for the D28, resulting in reduced investment for multi-table production lines
- Enhanced rigidity: Single-point clamping force is slightly lower than that of the D28 table; however, this heavy-duty model compensates for rigidity through a thicker tabletop and reinforced base frame, effectively meeting the requirements for heavy, large-scale components
Standard Tooling Kit
- Positioning components: Φ16 cylindrical pins, diamond pins, positioning blocks, right-angle positioning blocks, angle positioners
- Clamping components: quick-locking clamps, screw clamps, side clamps, vertical clamping blocks
- Support and extension components: adjustable support pillars, extension arms, V-blocks, height-equalizing blocks
- Accessories: connecting locking blocks, table protective plugs, graduated scales, lifting rings
Operational Benefits
- Cost Reduction: Eliminates the need for custom welding jigs for individual parts, achieves 100% tooling reusability, and lowers mold manufacturing costs
- Efficiency Improvement: Cuts tooling setup time by 70%, eliminates the need to fabricate new tooling for product changeovers, and supports batch production of diverse product types
- Quality Enhancement: Utilizes a unified, high-precision reference system, significantly improving the dimensional consistency of welded parts and reducing scrap rates
- Versatility: A single welding table handles the full range of processing—from precision small components to massive steel structures weighing several tons—thereby increasing workshop space utilization
