High Quality D16 System 16mm holes 3D Welding Table
| MOQ: | 1 PCS |
| Price: | 500-1000 USD |
| Standard Packaging: | 4000*2000*200mm |
| Delivery Period: | 15-20 work days |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union |
| Supply Capacity: | 500 units/month |
Detail Information
Place of Origin
WUXI
Brand Name
WUXI LEMAR
Certification
CE
Model Number
D16
Document
Main Material:
Q355 Steel / HT300 Cast Iron
Overall Flatness:
≤0.3 Mm / 1000 Mm
Load Capacity:
1 - 7 Ton
Machining Type:
5-sided Machining
Hole Tolerance:
±0.02mm
Edge Style:
Full Machined Edge
Anti-corrosion:
Rust-proof Treatment
Net Weight (Reference):
380kg ~ 680kg (Depends On Size)
Hole Diameter:
16mm
Highlight:
16mm hole welding table
,D16 system welding fixture
,3D welding table with holes
Product Description
High Quality D16 System 16mm holes 3D Welding Table
Product Overview
The high-quality D16 system 3D welding table features 16mm holes, a 50mm grid pattern, five-sided machining, and a wear-resistant nitrided finish. This represents the mainstream solution for welding precision small-to-medium-sized components. When paired with modular fixtures, it enables the creation of efficient, precise, and cost-effective welding setups, making it widely applicable in sheet metal fabrication, precision structural component manufacturing, and small-batch production.
Dimensions and Specifications
| NO | Welding Table Specification | Hole Diameter | Hole spacing | Material |
|---|---|---|---|---|
| 1 | 3000mm × 1500mm |
D16 welding table |
50mm × 50mm | Q355 steel/HT300 cast iron |
| 2 | 2400mm × 1200mm | 50mm × 50mm | Q355 steel/HT300 cast iron | |
| 3 | 2000mm × 1500mm | 50mm × 50mm | Q355 steel/HT300 cast iron | |
| 4 | 2000mm × 1000mm | 50mm × 50mm | Q355 steel/HT300 cast iron | |
| 5 | 1500mm × 1000mm | 50mm × 50mm | Q355 steel/HT300 cast iron | |
| 6 | 1200mm × 1000mm | 50mm × 50mm | Q355 steel/HT300 cast iron | |
| 7 | 1000mm × 1000mm | 50mm × 50mm | Q355 steel/HT300 cast iron |
Standard sizes as shown. Custom dimensions supported. Contact us for your specific requirements.
Structure and Features
3D Hole Pattern Design
- 5-Sided Machining: D16 holes are featured on the top surface and all four side panels of the 3D welding table, enabling clamping across X, Y, and Z axes.
- Modular System: The hole pattern is compatible with all standard D16 accessories (locating pins, clamps, squares, extension arms, etc.), allowing for rapid setup changes.
High-Quality Craftsmanship
- Gas Nitriding: The welding table surface offers high hardness, resistance to weld spatter adhesion, and high-temperature durability; it is easy to clean and ensures a long service life.
- Precision CNC Machining: Hole position tolerance is ±0.02mm with strictly controlled flatness, ensuring welding accuracy and repeatability.
- Robust Structure: Box-type or truss-style base design provides high rigidity and resistance to deformation, ensuring stability under long-term heavy loads.
Key Buying Points
- Tabletop Material: Nitrided steel is preferred (wear-resistant and slag-resistant); cast iron offers good cost-performance but has slightly lower toughness.
- Flatness: ≤0.3mm/1000mm for precision welding; ≤0.3mm is sufficient for standard welding.
- Load-bearing Capacity: 3-5 tons for standard applications; 7 tons or more for heavy-duty workpieces.
- Accessories: Ensure the inclusion of basic accessories such as locating pins, quick-acting clamps, 90° squares, and extension blocks.
Service and Support
- Provide professional selection guidance according to your workpiece size, welding type and production demands.
- Offer free layout design, solution planning and parameter consultation.
- Support customized table size, special surface treatment and personalized accessories.
- Supply detailed 3D welding table drawings, inspection reports and certification documents (CE).
High Quality D16 System 16mm holes 3D Welding Table – Reliable partner for all your welding jobs.
Get our best offer now!
